Implement Tyre
I-3C Implement Driving and Driven Wheel Tire
  • I-3C Implement Driving and Driven Wheel TireI-3C Implement Driving and Driven Wheel Tire

I-3C Implement Driving and Driven Wheel Tire

OXPLO Tires Co., Ltd., situated in Qingdao, Shandong Province, China, is a preeminent manufacturer of high-quality tires tailored for diverse applications. Leveraging decades of industry expertise, we take pride in delivering tires that are renowned for their durability and reliability. Notably, our I-3C Implement Driving and Driven Wheel Tires are specifically engineered to meet the stringent demands of agricultural machinery, ensuring optimal performance in various farming operations.

I-3C Implement Driving and Driven Wheel Tire

Introduction

Qingdao Oxplo Tire, is a company with over 20 years of tyres manufacturer. The I-3C Implement Driving and Driven Wheel Tire is a premium agricultural tire designed to meet the rigorous demands of modern farming equipment. Its advanced features and robust construction ensure optimal performance, durability, and safety in various field conditions.

I-3C Implement Driving and Driven Wheel Tire

Specifications

MODEL TIRE SPECIFICATION LOAD INDEX SPEED TIRE TYPE SECTION WIDTH
(MM)
OUTER DIAMETER
(MM)
MAXIMUM SPEED
(MM)
INFLATION PRESSURE
(KPA)
MAXIMUM
LOAD
(KG)
DESIGN RIM
WIDTH
PATTERN DEPTH
(MM)
I-3C 400/60-15.5 14 A8 TL 404 874 40 360 *3250/**2000 AG13.00 20.00
400/60-15.5 16 A8 TL 404 874 40 400 *2900/**2240 AG13.00 20.00
400/55-22.5 20 A8 TL 404 1012 40 550 *4250/**3000 AG13.00 25.50
400/55-22.5 16 A8 TL 404 1012 40 320 *3075/**2180 AG13.00 25.50
500/60-22.5 16 A8 TL 503 1173 40 500 *6000/x*4250 16.00DC 26.00
550/60-22.5 16 A8 TL 537 1254 40 300 *5300/**3750 16.00DC 25.00
600/55-22.5 16 A8 TL 611 1232 40 280 5600/**4000 20.00DC 26.00
600/50-22.5 16 A8 TL 611 1172 40 320 *5600/**4000 AG20.00 26.00
600/55-26.5 16 A8 TL 611 1333 40 240 *5300/**3750 AG20.00 26.00
700/50-22.5 12 A8 TL 700 1270 40 220 *5600/**4000 24.00DC 27.00
700/50-22.5 16 A8 TL 700 1270 40 280 *6700/**4750 24.00DC 27.00
500/45-22.5 16 A8 TL 503 1022 40 280 *3350/**2360 AG16.00 25.50
700/50-26.5 16 A8 TL 710 1333 40 240 *5800/**4125 AG24.00 26.00

• Size Range: Available in various sizes to fit different agricultural implements and machinery.
• Load Capacity: High load-bearing capacity, suitable for heavy-duty agricultural applications.
• Speed Rating: Meets or exceeds industry standards for speed ratings.
• Certifications: ISO, DOT, CCC, ECE (as per the information provided in the reference articles).

I-3C Implement Driving and Driven Wheel Tire

Key Features

1. High-Quality Materials: Manufactured using high-grade rubber compounds, the I-3C Implement Driving and Driven Wheel Tire is built to last. It can withstand the heavy loads and abrasion associated with agricultural work.
2. Optimal Traction: The unique tread pattern of the I-3C Implement Driving and Driven Wheel Tire provides excellent traction on both wet and dry surfaces. This ensures stable operation and reduced soil compaction.
3. Durable Construction: The tire's reinforced sidewall and robust belt structure ensure maximum durability and resistance to punctures and tears.
4. Versatile Applications: Suitable for both driving and driven wheels, the I-3C Implement Driving and Driven Wheel Tire can be used on a wide range of agricultural implements and machinery.
5. Easy Maintenance: The tire's design allows for easy removal and installation, minimizing downtime and maintenance costs.

I-3C Implement Driving and Driven Wheel Tire

Benefits

• Enhanced Safety: The excellent traction and stability provided by the I-3C Implement Tire reduce the risk of accidents and ensure safer operation.
• Long-Lasting Performance: The durable construction and high-quality materials ensure that the tire can withstand frequent use and heavy loads, providing long-lasting performance.
• Versatility: The tire's suitability for both driving and driven wheels makes it a versatile choice for various agricultural implements and machinery.
• Cost-Effectiveness: The easy maintenance and durability of the I-3C Implement Driving and Driven Wheel Tire reduce overall operating costs.

I-3C Implement Driving and Driven Wheel Tire

Customer Support

We provide comprehensive customer support, including product inquiries, technical assistance, and after-sales service. Our team of experts is always ready to assist you with any questions or concerns you may have about the I-3C Implement Driving and Driven Wheel Tire.

I-3C Implement Driving and Driven Wheel Tire

Please note that the specifications and benefits mentioned above may vary depending on the specific model and application. For more detailed information, please consult our product catalog or contact us directly.
