Qingdao Oxplo Tire, a renowned tire supplier in China for 20 years. Heavy Dump Truck OB-501 Tyre is a robust and reliable option for heavy-duty dump trucks. Its design is tailored to meet the demanding requirements of mining, construction, and other industrial applications. With superior durability, load-bearing capacity, and traction, the OB-501 ensures smooth and efficient operations in various environments.
|
(Model) |
(Specification) |
(Rim) |
(Inflated Size) |
(Maximum Tire Load At Different Maximum Speeds) /kg |
|||||
|
(Balanced Counterweight Forklift) |
(Industrial Vehicles) |
||||||||
|
(Outer Diameter) mm |
(Section Width) mm |
25km/h | 6km/h | 10km/h | 25km/h | ||||
|
(Driving Wheel) |
(Steering Wheel) |
||||||||
| OB501 | 4.00-8/3.00 | 3.00D-8 | 399 | 104 | 950 | 730 | 950 | 860 | 730 |
| 5.00-8/3.00 | 3.00D-8 | 443 | 124 | 1415 | 1090 | 1415 | 1285 | 1090 | |
| 6.00-9/4.00 | 4.00E-09 | 521 | 137 | 1885 | 1450 | 1885 | 1710 | 1450 | |
| 6.50-10/5.00 | 5.00F-10 | 565 | 151 | 2340 | 1800 | 2340 | 2125 | 1800 | |
| 7.00-12/5.00 | 5.00S-12 | 651 | 168 | 2920 | 2240 | 2920 | 2645 | 2240 | |
| 7.00-15/5.50 | 5.5-15 | 711 | 168 | 3545 | 2725 | 3545 | 3215 | 2725 | |
| 7.50-15/5.50 | 5.5-15 | 732 | 193 | 3900 | 3000 | 3900 | 3540 | 3000 | |
| 7.50-15/6.50 | 6.5-15 | ||||||||
| 8.25-15/6.50 | 6.5-15 | 802 | 208 | 4750 | 3650 | 4750 | 4300 | 3650 | |
| 15x4.5-8/3.00 | 3.00D-8 | 373 | 110 | 1040 | 800 | 1040 | 945 | 800 | |
| 15x4.5-8/3.25 | 3.251-8 | ||||||||
| 16x6-8/4.33 | 4.33R-8 | 411 | 152 | 1495 | 1150 | 1495 | 1360 | 1150 | |
| 18x7-8/4.33 | 4.33R-8 | 450 | 147 | 2145 | 1650 | 2145 | 1945 | 1650 | |
| 21x8-9/6.00 | 6.00E-09 | 521 | 190 | 2755 | 2120 | 2755 | 2500 | 2120 | |
| 23x9-10/6.50 | 6.50F-10 | 581 | 209 | 3445 | 2650 | 3445 | 3125 | 2650 | |
| 23x10-12/8.00 | 8.00G-12 | 574 | 246 | 3770 | 2900 | 3770 | 3420 | 2900 | |
| 27x10-12/8.00 | 8.00G-12 | 657 | 247 | 3900 | 3000 | 3900 | 3540 | 3000 | |
| 28x9-15/7.0 | 7.0-15 | 691 | 210 | 3900 | 3000 | 3900 | 3540 | 3000 | |
| 250-15/7.0 | 7.0-15 | 705 | 210 | 4745 | 3650 | 4745 | 4310 | 3650 | |
| 250-15/7.5 | 7.5-15 | ||||||||
| 300-15/8.0 | 8.0-15 | 806 | 251 | 5850 | 4500 | 5850 | 5310 | 4500 | |
| 350-15/9.75 | 9.75-15 | 810 | 296 | 7085 | 5450 | 7085 | 6430 | 5450 | |
| 200/50-10/6.50 | 6.50F-10 | 450 | 196 | 2470 | 1900 | 2470 | 2240 | 1900 | |
| 355/65-15/9.75 | 9.75-15 | 810 | 296 | 7800 | 6000 | 7085 | 6430 | 5450 | |
● Model: OB-501
● Application: Heavy Dump Truck
● Type: Solid or Pneumatic (Based on Variant)
● Dimensions: Various sizes available to fit standard dump truck rim specifications. (Exact dimensions not provided in reference articles.)
1. Durability:
o Manufactured using high-quality, abrasion-resistant rubber compounds for extended service life.
o Reinforced sidewall construction for added stability and durability.
2. Load Capacity:
o Engineered to handle heavy loads and uneven terrains with ease.
o Provides excellent load distribution and shock absorption.
3. Traction:
o Deep tread pattern ensures maximum traction and grip in all conditions.
o Optimized for both on-road and off-road applications.
● The Heavy Dump Truck OB-501 Tyre is designed to provide optimal performance in harsh environments, ensuring smooth and reliable operations.
● Heavy Dump Truck OB-501 Tyre’s superior durability and load-bearing capacity make it a cost-effective solution for heavy-duty applications.
● Available for customization based on specific requirements, such as tread pattern, material compound, and additional reinforcement.
● Manufacturer's warranty available on selected products. (Exact warranty details not provided in reference articles.)
● Technical support and after-sales service provided by the manufacturer's team of experts.
● Pricing and availability may vary depending on the region and specific requirements. Please contact the manufacturer or authorized dealers for more information.
